• max. printing area: 500 x 700 mm
• max. flock area: 400 x 500 mm
• squeegee-drive system: AC-Servo-drive, high-precision-spindle-drive,
• Pallet-drive: frequency controlled AC-Servo-Drive

Squeegee-System

• 4-Cylinder POWER-Squeegee-System
• Floodbars with mecanical way-adjustment for precise hight-leveling

Central Main-Control with touch-screen Monitor

• with Siemens-standard-modules
• microprocessor with diagnostic programm - easy to operate –
• control-keypads at every print station for fast set-up START, STOP, LIFT-UP/DOWN, Squeegee-movement; Squeegee-stroke-speed individual adjustable
• central electronic off-contact adjustable on the touch-screen

Flock-System

• high voltage from 10 - 80 kV adjustable
• with ground surveillance
• digital kV- and uA-measuring devices
• automatic high voltage discharge
• dosing time and flock time adjustable

Printing programmes

• 6-standard print programs + high density+cool-stop
• + sampling-start up - finishing programs+double-index+MULTIFLASH-program
• cleaning-program: in-between pallet-stop, left / right, free wheel-mode
